西安紫光国芯是国内领先的专业DRAM KGD解决方案提供商
晶片级客户需要能够满足他们对高品质、长期技术支持、供货保证和较低成本等诸多要求的存储器合作伙伴。西安紫光国芯是高品质利基型DRAM存储器完整解决方案提供商,是晶圆级客户的DRAM存储器专业合作伙伴。
· 为KGD客户提供完整的DRAM产品组合,包括SDR、DDR、DDR2、DDR3、DDR4、PSRAM、LPDDR、LPDDR2、LPDDR3、LPDDR4 DRAM
· 支持数据速率 4266Mbps LPDDR4X、2133Mbps LPDDR3、1066Mbps LPDDR2、1600Mbps DDR3 DRAM、800Mbps PSRAM 、1333Mbps DDR2 DRAM、400Mbps DDR DRAM、166Mbps SDR DRAM。
Product |
PN. | Density | Voltage(v) | Freq.(MHz) | Tj Scope | ECC | Status |
SDR | SCKM33S128XX1AAXX | 128Mb | 3.3 | 167 | -40℃~ +125℃ | Y | MP |
SDR | SCKM33S256XX1AAXX | 256Mb | 3.3 | 167 | -40℃~ +125℃ | Y | MP |
SDR | SCKM33S512XX1AAXX | 512Mb | 3.3 | 167 | -40℃~ +125℃ | Y | MP |
DDR | SCKY25D512XX0AAXX | 512Mb | 2.5 | 200 | -40℃~ +125℃ | Y | MP |
DDR | SCKY25D1GXX1AAXX | 1Gb | 2.5 | 200 | -40℃~ +125℃ | Y | MP |
DDR2 | SCKY18T512XX0AAXX | 512Mb | 1.8 | 533 | -40℃~ +125℃ | Y | MP |
DDR2 | SCKL15T512XX0AAXX | 512Mb | 1.5 | 667 | -40℃~ +125℃ | MP | |
DDR2 | SCKL18T512XX0AAXX | 512Mb | 1.8 | 667 | -40℃~ +125℃ | MP | |
DDR2 | SCKY18T1GXX1AAXX | 1Gb | 1.8 | 533 | -40℃~ +125℃ | Y | MP |
DDR2 | SCKH18T2GXX0AAXX | 2Gb | 1.8 | 533 | -40℃~ +125℃ | MP | |
DDR3 | SCKK13H1GXX0AAXX | 1Gb | 1.5/1.35 | 1066 | -40℃~ +125℃ | MP | |
DDR3 | SCKY15H1GXX1AAXX | 1Gb | 1.5 | 800 | -40℃~ +125℃ | Y | MP |
DDR3 | SCKH15H2GXX0AAXX | 2Gb | 1.5/1.35 | 800 | -40℃~ +125℃ | MP | |
DDR4 | SCKS12Q8GXX0AAXX | 8Gb | 1.2 | 1333 | -40℃~ +125℃ | Y | MP |
LPDDR | SCKY18K1GXX1AAXX | 1Gb | 1.8 | 200 | -40℃~ +125℃ | Y | MP |
LPDDR2 | SCKU4BL256XX0AAXX | 256Mb | 1.8/1.2 | 533 | -40℃~ +125℃ | MP | |
LPDDR2 | SCKX4BL512XX0AAXX | 512Mb | 1.8/1.2, 1.8/1.1 | 667(1.2), 400(1.1) | -40℃~ +125℃ | MP | |
LPDDR2 | SCKL4BL1GXX0AAXX | 1Gb | 1.8/1.2 | 533 | -40℃~ +125℃ | MP | |
LPDDR3 | SCKL12M1GXX0AAXX | 1Gb | 1.8/1.2 | 1066 | -40℃~ +125℃ | MP | |
LPDDR4 | SCKG11N2GXX0AAXX | 2Gb | 1.8/1.1/1.1 | 1600 | -40℃~ +105℃ | Y | MP |
LPDDR4 | SCKG11N4GXX0AAXX | 4Gb | 1.8/1.1/1.1 | 1600 | -40℃~ +105℃ | Y | MP |
LPDDR4 | SCKC11N4G160AAXX | 4Gb | 1.8/1.1/1.1 | 2133 | -40°℃~ +105°C | CS | |
LPDDR4X | SCKG11R2GXX0AAXX | 2Gb | 1.8/1.1/0.6 | 1600 | -40℃~ +105℃ | Y | MP |
LPDDR4X | SCKG11R4GXX0AAXX | 4Gb | 1.8/1.1/0.6 | 1600 | -40℃~ +105℃ | Y | MP |
LPDDR4X | SCKC11R4G160AAXX | 4Gb | 1.8/1.1/1.1 | 2133 | -40℃~ +105℃ | CS | |
PSRAM | SCKM18X016800AAXX | 16Mb | 1.8 | 400 | -40℃~ +125°C | ES | |
PSRAM | SCKM18X032800AAXX | 32Mb | 1.8 | 400 | -40℃~ +125°C | ES | |
PSRAM | SCKM18X064800AAXX | 64Mb | 1.8 | 400 | -40℃~ +125°C | ES | |
PSRAM | SCKW18X128XX0AAXX | 128Mb | 1.8 | 400 | -40℃~ +125℃ | CS |
